High Sensitivity
Low temperature Drift
LCD display optional
Light construction
Internal auto compensation
Temperature compensation
The oil and gas industry
Industrial environmental monitoring
| Item | Technical Specification |
|---|---|
| Range(concentration) | 0-10PPM 0-50PPM 0-100PPM |
| Accuracy | ±2%F.S(25℃) |
| Supply | 12-24VDC 7-24VDC |
| Output | 4-20mA,0-2V,0-5V,0-10V,RS485 |
| Power Consumption | <0.25W |
| Warm Up Time | 3min |
| Response Time | <15s |
| Temperature Drift | ≤0.2%FS/℃ |
| Repeatability | <±1%FS |
| Operating Temperature | -20℃-+60℃@15-80%RH |
| Storage | -40-70℃@20%-90%RH |
| Shell Material | ABS |
The ammonia gas detector sensor has many great features. First, it is very sensitive and can find small amounts of ammonia. This is important in food processing and the pharmaceutical industry. In these areas, ammonia levels must be very low.
The NH3 ammonia sensor has high sensitivity. Second, the response speed is fast. The ability to quickly respond to changes in ammonia levels gives us important time to take action. This is important for sensors that detect ammonia gas.
Environmental monitoring:
◉Ammonia is a pollutant found in the air. It mainly comes from farming, factories, and raising livestock and poultry. Urban monitoring stations and weather stations use ammonia sensors. These sensors check the ammonia levels in the air.
◉In indoor spaces, ammonia can come from materials used in buildings. These include urea-formaldehyde resins and some cleaning products. Ammonia sensors can check indoor ammonia levels. This helps keep residents healthy.
Agriculture:
◉In livestock and poultry farms, ammonia is a harmful gas. An ammonia gas detector can check ammonia levels in real time. High ammonia levels can irritate animals’ breathing systems. This can lead to slow growth, lower immunity, and a higher risk of respiratory diseases.
◉Some nitrogen fertilizers are made using ammonia. Ammonia sensors help check for leaks in the production area. This keeps workers safe.
During fertilization, ammonia sensors can track ammonia released from fertilizers. This includes ammonia water and ammonium bicarbonate.
Industrial circle:
◉In the chemical industry, ammonia is an important raw material. It is used to make products like nitric acid and urea.
Ammonia sensors, or NH3 sensors, are used to check ammonia flow and concentration in production. In making urea, it is important to control how much ammonia is used. This helps keep the product safe and of good quality.
| Model | CDW-17A |
|---|---|
| OEM/ODM | Available |
| MOQ | 1PCS |
| Lead Time | 5-7 days |
| Certification | CE-EMC, RoHS, ISO9001 |
| Size | 10cm*10cm*5cm |
| Weight | 0.28KG |
| Payment | T/T, L/C or Credit-card |
